VA Imaging ME2S-1260-28U3C-VA 1" Color CMOS (OnSemi XGS12000) Camera, 13 Megapixels, 4096 x 3072, 28 fps, Global Shutter, C-Mount, USB 3.0 Output

Compact USB3 High-Resolution Imaging Cameras Featuring XGS12000

The ME2S USB3 lineup offers a highly compact industrial USB3 vision camera solution. It incorporates high-resolution global shutter sensors from Sony and Gpixel. Typical uses for these cameras include machine vision, automation, laboratory environments, research and development, among others. USB3 provides a fast and cost-effective interface, compatible with all PCs. This camera is ideal if you require:
- An industrial camera with a compact 29x29mm footprint
- High-resolution image capture of dynamic subjects
- Compatibility with x86 computers and embedded ARM V7 & ARM V8 platforms

Reliability, Warranty & Product Longevity

Daheng Imaging manufactures over 100,000 industrial cameras annually, adhering to stringent quality standards. The mean time between failures (MTBF) exceeds 400,000 hours (equivalent to 45 years of continuous operation). These industrial cameras are TÜV Rheinland certified and come with a 3-year warranty. Each model remains available for a minimum of 7 years post-launch, with many models supported for significantly longer. For additional details on our product life cycle management, please refer to the linked article.

Industrial Color Imaging Camera

Color cameras utilize a Bayer filter array to generate color images. The RGB value of each pixel is computed by combining the pixel s own value with those of adjacent pixels. This process results in images that are generally less sharp compared to monochrome cameras.
Because of the RGB filters, each pixel receives approximately 66% fewer photons under white light conditions than a monochrome sensor, making color cameras less sensitive to light. To address this limitation, the following strategies can be applied:
- Enhance illumination intensity
- Increase camera gain
- Extend shutter speed or exposure duration
- Choose a sensor with higher light sensitivity
- Opt for a lens with improved light transmission

Enhanced Vision Camera Capabilities

The ME2S USB3 vision camera series includes both fundamental and advanced functionalities, such as:
- Programmable region of interest (ROI) enabling higher frame rates through partial scanning
- Adjustable gain, exposure, and white balance settings (white balance applicable only to color models)
- Support for automatic gain, exposure, and white balance adjustments (auto white balance limited to color variants)
- Four acquisition modes: single frame, continuous, software-triggered, and external-triggered acquisition
- Trigger options including Frame Start and Frame Burst Start
- Color correction features to enhance image quality (exclusive to color models)
- Exposure delay settings to minimize strobe timing effects
- Compliance with GenICam and GigE Vision standards, allowing seamless integration with third-party software like HALCON and LabVIEW
- Optimized software package designed to reduce CPU utilization on 32/64-bit Windows hosts
- Multiple example applications and an easy-to-use SDK supporting various programming environments
- Certifications and standards compliance: CE, RoHS, GenICam, USB3 Vision

The extensive feature set positions the ME2S USB3 Vision camera series as an excellent option for demanding image processing applications.
