Azure Photonics AZURE-IR01320B9M 1/2.3" 1.30mm (Fisheye) F2.0 Fixed Iris M12 (S-Mount) Lens, IR Corrected, 9 Megapixel Rated

Model #
AZURE-IR01320B9M
Availability
Typically 7-10 days
Shipping
Calculated at checkout
$150.00
Quantity


Technical Information

Azure Photonics AZURE-IR01320B9M 1/2.3" 1.30mm (Fisheye) F2.0 Fixed Iris M12 (S-Mount) Lens, IR Corrected, 9 Megapixel Rated

Format: 1/2.3"

Focal Length: 1.30mm

Aperture: F2.55

Iris Type: Fixed

Mount: M12 (S-Mount)

SPECIFICATIONS



Resolution 9.0Mega-pixel
Format 1/2.3
Mount M12x 0.5
Focal length 1.3mm
Iris Type Fixed
F/No 2.0
Back Focus 3.2mm
Angle of View 195°×195°×195°
WD 65mm
Focus Extend 0.1m~∞
F-Theta Distortion <-0.7%
Weight 24.5g
Dimension ¢32x17.2



Downloads:




AZURE-IR01320B9M Specification Sheet (PDF)
