VS Technology SV-0914H 2/3" 9mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

Model #
VST SV-0914H
Availability
Typically 2-4 days
Shipping
Calculated at checkout
$120.00
Quantity


Technical Information

VS Technology SV-0914H 2/3" 9mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

Format: 2/3"

Focal Length: 9 mm

Aperture: F1.4–close

Iris Type: Manual

Mount: C-Mount

Specifications

Focal Length (f) 9mm
Aperture F1.4 ~ Close
Angle of view (2/3") 43.4° x 51.0° (Diagonal: 65.5°)
M.O.D 100mm
Mount C-mount
Filter Thread M27 P=0.5
TV distortion (2/3") -1.94%
Weight (approx.) 54 g
Dimension Ø 29.5 (MAX) x L = 34mm



Downloads:


SV-0914H Spec Sheet (PDF)
