VS Technology SV-2514H 2/3" 25mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated
Model #
VST SV-2514H
VST SV-2514H
Availability
Typically 2-4 days
Typically 2-4 days
Shipping
Calculated at checkout
Calculated at checkout
$0.00
Technical Information
VS Technology SV-2514H 2/3" 25mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated - Compact Model
Format: 2/3" (will also cover 1/1.2" size sensor)
Focal Length: 25 mm
Aperture: F1.4–16
Iris Type: Manual
Mount: C-Mount
Note: This lens model has been tested on 1/1.2" size sensor (Sony IMX249 & IMX174) and will provide full coverage.
| Focal Length (f) | 25mm |
| Maximum Aperture Ratio | 1:1.4 |
| F/# | F1.4 ~ F16 |
| Angle of view (2/3") | 15.0° x 20.0° (Diagonal: 24.8°) |
| M.O.D | 150mm |
| Flange back | 17.526mm |
| Operation of Iris & Focus | Manual |
| Mount | C-mount |
| Filter Thread | M27 P=0.5 |
| Wavelength | Visible |
| TV distortion (2/3") | -0.08% |
| Sensor size (max.) | 2/3" |
| Weight (approx.) | 65.0 g |
| Dimension | Ø 30 (MAX) x L = 36.0mm |
Downloads:
SV-2514H Technical Drawing (PDF)
