  • Ikegami ISD-A15S Ikegami 1/3.2" CMOS Color CS-Mount Compact Cube Camera, NTSC, 1280 H x 960 V, 525 TVL, Hyper WDR, Digital Day/Night, Defog, 24VAC / 12VDC

    Model #
    IK ISD-A15S
    Typically 1-2 days for shipment
    Calculated at checkout

    Technical Information

    Resolution:  1280 H x 960 V

    Imager Size: 1/3.2"

    Output: Analog (NTSC) (via BNC)

    Color/Monochrome: Color (with Day/Night)

    Mount: CS-Mount


    Additional Information

    The ISD-A15S 1.23MP Hyper-Dynamic VBS Compact Cube Camera from Ikegami offers wide dynamic range, high sensitivity, and high resolution using a 1/3.2" CMOS sensor with digital processing technology. It is designed to reproduce clear and natural images even in locations with sharp brightness contrasts in areas with lots of windows, like lobby entrances. Featuring a compact cubical body of just 2.05 x 2.05 x 2.16", it can be deployed in a wide variety of locations.

    Hyper Wide Light Dynamic Range (Hyper WDR)
    The Hyper WDR function provides compensation for extremely bright and dark areas in a scene. High-contrast lighting situations may occur outdoors and when looking through a glass door or window to the outside. WDR technology allows bright and dark subjects to be captured and viewed clearly and with natural color.

    Compact Body

    The ISD-A15S's compact cubical body allows for flexible positioning. The camera fits into a variety of outdoor housings (available separately) and can be used to monitor ATM machines.

    Defog Function

    This function enables the ISD-A15S to capture clear images under foggy conditions.

    High-Quality Images and High Resolution

    The camera is designed to deliver smear-free, low-noise video. Its DSP (Digital Signal Processor) enhances details to achieve crisp and sharp images with a high signal-to-noise ratio and 700 TVL horizontal resolution.

    Ikegami ISD-A15S Specs

    Image Sensor 1/3.2" CMOS
    Total Pixel Number Approx. 1.23 MP, 1280 x 960
    Scanning System NTSC: 525 TV lines / 59.94 Hz, 2:1 interlaced
    Sync System Internal sync (crystal lock)
    Video Output VBS 1.0 V p-p / 75 Ohms
    Horizontal Resolution 700 TV lines
    S/N Ratio 50 dB (p-p/rms) or better
    Minimum Illumination 0.1 lx / f/1.4 (color, VBS output 50%)
    Day/Night Mode Built-in, auto/manual selectable digital day/night
    Wide Dynamic Range Built-in and variable
    AGC On (AGC, HYPER-AGC) / off (low, mid, and high) selectable
    Defog Built-in
    White Balance Control ATW (indoor/outdoor/auto1/auto2) / push / pushlock / manual
    Detail Correction Built-in
    Digital Noise Reduction Built-in, on/off selectable
    Color Rolling Reduction Built-in, on/off selectable
    Privacy Masking Built-in (max 16 zones)
    Camera ID Up to 24 characters (alphanumerical & symbols)
    Lens Mount CS-mount (C-mount adapter available separately)
    Auto Iris Control DC iris, level adjustable
    Lens Flange Focus Built-in and adjustable
    Input and Output Connectors BNC, video output
    4-pin lens connector (compatible with plug E4-191J-150 and equivalent)
    2-pin 12 VDC / 24 VAC input
    Power Requirements 24 VAC +/-10%, 50/60 Hz
    12 VDC (10.5 to 15 V)
    Power Consumption 2 W
    Operating Temperature 13.5 to 122°F / -10 to 50°C
    Humidity 30-90% RH (no condensation)
    Dimensions 2.05 x 2.05 x 2.16" / 5.2 x 5.2 x 5.5 cm
    Weight 0.44 lb / 200 g
    Packaging Info
    Package Weight 1.1 lb
    Box Dimensions (LxWxH) 6.2 x 4.5 x 3.5"



    pdf-icon.png ISD-A15S Datasheeet
