HIKROBOT MVL-HF5024M-10MP 1/1.8" 50mm F2.4 Manual Iris C-Mount Lens, Anti-Vibration, NIR Sensitivity, 10 MP Rated

SKU:
HIK MVL-HF5024M-10MP
Availability:
Typically 3 Weeks
$136.00
Current Stock:

HIKROBOT MVL-HF5024M-10MP  1/1.8" 50mm F2.4 Manual Iris C-Mount Lens, Anti-Vibration Performance, 2.1 Micron Pixel Support, NIR Sensitivity, 10 Megapixel Rated



Key Feature

  • Ultra high resolution and consistency of image clarity

  • Bigger aperture, lower distortion and higher relative illumination rate

  • Achromatic optical system design, Better imaging performance with color camera

  • Excellent vibration resistance performance, optical axis shifting within pixel level

  • Good stability at high and low temperature

  • Multi layer and broadband coating design, compatible with visible and near-infrared applications

  • NIR Sensitivity



Model
Model No. MVL-HF5024M-10MP
Type Fixed focal length, Manual iris, 10MP, FA Lens
Parameter
Focal Length 50mm
Aperture F2.4~F16
Image Circle Φ9mm(1/1.8")
Distortion 0.03%
Control Iris: Manual
Focus: Manual
Operating Temperature -10~50
Angle of View 1/1.8”
Interface C-Mount
Flange Back Length 17.526mm
Filter Thread M27×0.5
M.O.D 0.3m
Dimension Φ29×52mm
Weight 85.9g
Field of View D: 9.10° H: 7.48° V: 5.00°



Download Specification Sheet:


HIKRobot Datasheet
