Goyo Optical GM10HR35028MCN 2/3" 50.0mm F2.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.02% Distortion, Broadband Coating (400-900nm)

SKU:
GOY GM10HR35028MCN
Availability:
Typically 2-3 Days for Shipment
$917.00
Current Stock:

Format: 2/3"

Focal Length: 50mm

Aperture: F2.8

Iris Type: Manual Iris

Mount: C-Mount Lens



Additional Information

10-Megapixel Rated, -0.02% Distortion, 200 lp/mm Resolution, Broadband Coating (400-900nm).



Focal Length (mm) 50
Lens Type Fixed
Image Size (mm) 2/3" (Φ11)
Iris Range (F-stop) F2.8 ~ F16
Focusing Range (m) 0.1 ~ ∞
Iris Control Manual
Focus Control Manual
Shooting Range at M.O.D. (mm) 19.1(H) x 14.3(V)
Angle of View 2/3" (°) 10.1 x 7.6
Angle of View 1/2" (°) 7.3 x 5.5
Angle of View 1/3" (°) 5.5 x 4.1
Horizontal Angle of View (°) 10.1°
Vertical Angle of View (°) 7.6°
Diagonal Angle of View (°) 12.6°
Horizontal Shooting Range at M.O.D. (mm) 19.1
Vertical Shooting Range at M.O.D. (mm) 14.3
Diagonal Shooting Range at M.O.D (mm) 23.8
Resolution (Center, Corner) 200lp/mm, 160lp/mm
TV Distortion (%) -0.02
Back Focus in Air (mm) 12.8
Mount C-mount
Filter Thread Size (mm) M30.5 x P0.5
Minimum Focus Distance (m) 0.1
Flange Back in Air (mm) 17.526
Front/Rear Effective DIA (mm) Φ25.0, Φ12.5
Exit Pupil (mm) -70.9
Size (mm) Φ38 x 77
Weight (g) 170
Temperature Range (°C) -10 ~ +50




Downloads:





← Back to Goyo Optical Lens Page



Lens Type:
50mm
Format:
2/3"
Megapixel Rating:
10 MP
