WORLDWIDE DISTRIBUTOR OF INDUSTRIAL VIDEO PRODUCTS RMA Electronics

  • AZURE Photonics AZURE-2518M10M 2/3" 25mm F1.8 Manual Iris C-Mount Lens, Low Distortion, 10 Megapixel Rated

    Model #
    AZURE-2518M10M
    Availability
    Typically 7-10 days
    Shipping
    Calculated at checkout
    $328.00
    Quantity


    Technical Information

    AZURE Photonics AZURE-2518M10M  2/3" 25mm F1.8 Manual Iris C-Mount Lens, Low Distortion, 10 Megapixel Rated

    Format: 2/3"

    Focal Length: 25mm

    Aperture: F1.8

    Iris Type: Manual

    Mount: C-Mount

    SPECIFICATIONS

    Resolution: 200lp/mm (10MP)
    Format :  2/3"
    Mount : C
    Focal Length: 25mm
    F/No range: F1.8~F32
    Back Focus :  12.59mm
    Iris Type :  Manual Iris
    Angle of View(D×V×H) :  2/3" 24.81°× 15.04°× 19.96°
    1/2" 18.18°× 10.97°×14.59°
    1/3" 13.69°× 8.24°×10.97°
    1/4" 9.15°× 5.50°×7.32°
    Distortion :       <-0.09%
    Length to sensor 53.38
    Relative illumination 52%
    CRA 32
    Front Diameter 38
    Operating Temperature -20℃ to +65℃
    Working Distance: infinity-0.2
    Coating Wavelength:   400nm~950nm
    Filter Thread :  M30.5x 0.5
    Dimension : ¢38 x 40.2mm
    Weight : 140g

    Dimensions:




    Downloads:


    AZURE-2518M10MM Specification Sheet (PDF)
