  • AZURE Photonics AZURE-5018M10M 2/3" 50mm F1.8 Manual Iris C-Mount Lens, Low Distortion, 10 Megapixel Rated

    Model #
    AZURE-5018M10M
    Availability
    Typically 7-10 days
    Shipping
    Calculated at checkout
    $328.00
    Quantity


    Technical Information

    AZURE Photonics AZURE-5018M10M 2/3" 50mm F1.8 Manual Iris C-Mount Lens, Low Distortion, 10 Megapixel Rated

    Format: 2/3"

    Focal Length: 50mm

    Aperture: F1.8

    Iris Type: Manual

    Mount: C-Mount

    SPECIFICATIONS

     Resolution:  200lp/mm (10MP)
     Format :
     2/3"
     Mount :
     C
     Focal Length:
     50mm
     F/No range :
     F1.8~F22
     Back Focus :   13.86mm
     Iris Type :
     Manual Iris
     Angle of View(D×V×H) :
     2/3"  11.46°x6.86°x9.16°
     1/2"  8.32°x5°x6.86°
     1/3"  6.24°x3.74°x5°
     Distortion :       <-0.2%
     Length to sensor  52.2
     Relative illumination  80%
     CRA  8.44
     Front Diameter  38
     Operating Temperature  -20℃ to +65℃
     Working Distance:  infinity-0.5
     Design Wavelength:
     400nm~950nm
     Filter Thread :
     M34x 0.5
     Dimension :
     ¢38 x 43.5mm
     Weight :
     124g

    Dimensions:




    Downloads:


    AZURE-5018M10M Specification Sheet (PDF)
