VS Technology VS-2514H1-SWIR 1" 25mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, SWIR Type (700-2000nm)
Model #
VST VS-2514H1-SWIR
VST VS-2514H1-SWIR
Availability
Typically 7-10 days
Typically 7-10 days
Shipping
Calculated at checkout
Calculated at checkout
$0.00
Technical Information
VS Technology VS-2514H1-SWIR 1" 25mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, SWIR Type (700-2000nm)
Format: 1"
Focal Length: 25 mm
Aperture: F1.4–16
Iris Type: Manual
Mount: C-Mount
| Focal Length (f) | 25mm (25.42) |
| Maximum Aperture Ratio | 1:1.4 (1.44) |
| F/# | 1.4 ~ 16 |
| Angle of view (1") | 25.1° x 25.1° (Diagonal: 35.4°) |
| M.O.D | 300mm |
| Flange back | 17.526mm |
| Operation of Iris & Focus | Manual |
| Mount | C-mount |
| Filter Thread | M30.5 P=0.5 |
| Wavelength | Short Wave IR |
| TV distortion (1") | -0.46% |
| Sensor size (max.) | 1" |
| Weight (approx.) | 84 g |
| Dimension | Ø38 (MAX) x L = 33.5mm |
Downloads:
VS-2514H1-SWIR Spec Sheet (PDF)
VS-2514H1 Technical Drawing (PDF)
