Schneider Optics 21-1081347 Xenon-Topaz 1.1" 25mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

Model #
SCH 21-1081347
Availability
Typically 2-4 days
Shipping
Calculated at checkout
$875.00
Quantity


Technical Information

Schneider Optics 21-1081347 Xenon-Topaz 1.1" 25mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

Format: 1.1"

Focal Length: 25mm

Aperture: F2.0

Iris Type: Manual Iris

Mount: C-Mount


Additional Information

These compact and lightweight lenses are designed for modern CCD and CMOS sensors up to 12 megapixel resolution and with an image circle diameter of 1.1" and a pixel size down to 3.0 µm.

The robust mechanical design with lockable iris and focus is resistant to vibrations and guarantees an extremely high and uniform image quality over the entire sensor even under harsh conditions. The broadband coating covers the range from 400 to 1,000 nm (VIS + NIR).

Our Xenon-Topaz lenses are optimized for 1 m to infinity working distance making them perfectly suited for applications like traffic, high-end surveillance, robot vision, 3D-Measurement, food processing, machine vision and other image applications.

Key Features

  • High-resolution optics for up to 12 megapixel sensors
  •  Optimized for 1 m to infinity working distance
  • Broadband coating (400 - 1,000 nm)
  • Optional ruggedized for harsh surroundings
  • Vibration insensitivity for stable imaging performance
  • Focus and iris setting lockable

 Applications

  • Traffic
  • High end surveillance
  • Robot vision
  • 3D-Measurement
  • Machine vision

Technical Specifications

F# range

2.0 – 16

Focal length

24.2 mm

Image circle

17.6 mm

Transmission

400 - 1000 nm

Interface

C-Mount

Weight

tbd.



Filter thread

M30.5 x 0.5

Code no.

1081347

Download Specification Sheet:




Schneider Optics 21-1081347 Datasheet




Schneider Optics 21-1081347 Technical Drawing
