  • Kowa LM50JCM 2/3" 50mm F2.8 Manual Iris C-Mount Lens, 2 Megapixel Rated

    Model #
    KOW LM50JCM
    Availability
    Typically 2-4 days
    Shipping
    Calculated at checkout
    $186.00
    Quantity


    Technical Information

    Format: 2/3"

    Focal Length: 50mm

    Aperture: F2.8

    Iris Type: Manual Iris

    Mount: C-Mount



    Additional Information

    2 Megapixel Rated, Low Distortion.



    Focal Length (mm) 50
    Lens Type Fixed
    Image Size (mm) 2/3" (Φ11)
    Iris Range (F-stop) F2.8 ~ F22
    Focusing Range (m) 0.2 ~ ∞
    Iris Control Manual
    Focus Control Manual
    Shooting Range at M.O.D. (mm) 29.3(H) x 21.9(V)
    Angle of View 2/3" (°) 9.6 x 7.2
    Angle of View 1/2" (°) 7.0 x 5.2
    Angle of View 1/3" (°) 5.2 x 3.9
    Resolution (Center, Corner) 120lp/mm, 100lp/mm
    TV Distortion (%) -0.03
    Back Focus in Air (mm) 35.5
    Mount C-mount
    Filter Thread Size (mm) M27 x P0.5
    Flange Back in Air (mm) 17.526
    Front/Rear Effective DIA (mm) Φ21.7, Φ14.6
    Exit Pupil (mm) -63.7
    Size (mm) Φ34 x 55
    Weight (g) 92
    Temperature Range (°C) -10 ~ +45
