Kowa LM12JC3M2 2/3" 12mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

Typically 2-4 days
Current Stock:

Kowa LM12JC3M2 2/3" 12mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

Format: 2/3"

Focal Length: 12mm

Aperture: F1.4

Iris Type: Manual Iris

Mount: C-Mount Lens

Product Information LM12JC3M2

Megapixel lens
Locking screws for iris and focus
Metal mount
Metal housing

Focal Length (mm): 12
Sensor Size: 2/3"
Pixel Size (µm): 4
Mount: C-mount
Iris Control: Manual
Iris Range (F-Stop): 1,4
Lens Type: Fixed Focal Lens
Wavelength Range: Broad Band Coating (380nm - 1000nm), VIS (380nm - 780nm)
Focusing Range (m): 0,15 - ∞
Focus Control: Manual
Shooting range at MOD, horizontal (mm): 110
Shooting range at MOD, vertical (mm): 82,5
Resolution, Center: 130
Resolution, Corner: 110
Distortion (TV) (%): -0,07
Back focus in air (mm): 11,7
Filter Size (mm): M27 x P0,5
Size (mm): Ø34 X 37
Weight (g): 85
Temperature Range (): -10°C - +50°C
Series: JC3M2
Application: Machine Vision


Datasheet Download:


Kowa LM12JC3M2 Datasheet



JC3M2 Series Brochure
