Fujinon HF12.5SA-1 2/3" 12.5mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

FUJ HF12.5SA-1
Typically 1-2 days
Current Stock:

Format: 2/3"

Focal Length: 12.5mm

Aperture: F1.4

Iris Type: Manual Iris

Mount: C-Mount


Additional Information

Locking screws for focus and iris.  5 megapixel rated for machine vision.

HF12.5SA-1 - High-resolution design, providing support for up to 5 megapixel camera resolution. Rear focusing system provides improved performance in macro photography. Wide-aperture (F1.4) design achieves clear images under low light intensity. Enhanced image recognition accuracy achieved by reduction of distortion and improvement of illumination uniformity. Robust enclosure resistant to vibrations and shocks. Equipped with locking knobs for the iris and the focus.


Mount C
Focal length 12.5 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 16.07 mm
Exit Pupil Position (From Image Plane) -101 mm
Object Dimensions at M.O.D. 83 × 62 mm
Angular Field of View 38°47′ × 29°35′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 295 g



Download Datasheet:


Lens Type:
12mm / 12.5mm
Megapixel Rating:
5 MP
Iris Type:
Mount Type:
C Mount
