Fujinon HF12.5HA-1S 2/3'' 12.5mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated
FUJ HF12.5HA-1S
Typically in stock
Calculated at checkout
Technical Information
Format: 2/3"
Focal Length: 12.5mm
Aperture: F1.4
Iris Type: Manual Iris
Mount: C-Mount
Additional Information
Formerly model HF12.5HA-1B. Locking screws on focus and iris. 1.5 megapixel rated for machine vision.
HF12.5HA-1S - Design achieving the high-resolution, supporting up to 1.5 megapixel cameras. Designed for low distortion, enabling faithful image input. Compact, lightweight and robust design, supporting various systems. Focus & iris lock tab provided, supporting environments such as vibration.
|
Mount |
C | |
|---|---|---|
|
Focal length |
12.5 mm | |
|
Focus |
Manual | |
|
Iris Range |
F1.4 - F16 | |
|
Iris |
Manual | |
|
Back Focal Distance (In Air) |
15.09 mm | |
|
Exit Pupil Position (From Image Plane) |
-31.3 mm | |
|
Object Dimensions at M.O.D. |
78 × 58 mm | |
|
Angular Field of View |
38°47′ × 29°35′ | |
|
Focusing Range (From Front of the Lens) |
∞ - 0.1 m | |
|
Filter Thread |
M25.5 × 0.5 mm | |
|
Mass |
45 g | |
Downloads:
HF12.5HA-1S Technical Drawing (PDF)
HF-HA Series: Upgrade with Anti Shock & Vibration Technology
We are happy to announce the update of the popular Fujinon DF/HF-HA-1B lens series to ruggedized versions equipped with the unique Fujinon “Anti-shock & Vibration” technology. The Fujinon HF-HA-1S upgrade provides vibration mitigation and shock absorption within the existing design, so the compact form factor remains. The optical performance of the upgraded series is identical to that of the Fujinon HF-HA-1B.
