Format: 1/1.8"
Focal Length: 16.7-1000mm (33.4-2000mm w/ 2X)
Aperture: F3.5
Iris Type: DC or Video (Specify)
Mount: C-Mount
Additional Information:
Video Auto-Iris, Manual Iris Override, Servo and RS-232 Control, Presets, Day/Night, Focus Assist (Auto-Focus), 2 Megapixel Rated (HD), Optical Stabilization Feature
Offering F3.5 brightness and 60x zoom (focal length of 2000mm when used with an extender), these lenses are suited for long range surveillance, including harbor surveillance. The compact and lightweight design allows establishment of compact remote surveillance systems. Day/Night capability for high-quality imaging around the clock. Equipped with a 2x extender that can see the actions of a person at a distance of 4km. Multiple power sources supported, can use existing control systems. Iris Override function allows manual iris adjustment.
Sensor Size (max.) |
1/1.8" |
Resolution |
2 Megapixel / Full HD |
Focal Length (1x) |
16.7 ~ 1000 mm |
Focal Length (2x) |
33.4 ~ 2000 mm |
Zoom Ratio |
60x |
2x Extender |
Yes |
Mount |
C |
Iris Range (1x) |
F3.5 ~ F16 |
Iris Range (2x) |
F7.0 ~ F32 |
Max. Relative Aperture |
1:3.5 |
MOD |
5 m |
ND Filter |
Yes (1/8 + 1/64) |
VLC Filter |
Yes |
Autofocus |
Yes |
OIS |
Yes |
Opt. Axis Adjustment |
Yes |
Lens Control Interface |
Serial |
Control Zoom |
Speed+Position |
Control Focus |
Speed+Position |
Control Iris |
Auto (DC)+Position |
Potentiometer Zoom |
Yes |
Potentiometer Focus |
Yes |
Potentiometer Iris |
Yes |
Day&Night |
Yes – IR Correction |
Back Focal Distance |
24.85 mm |
Flange Focal Length |
17.526 mm |
Exit Pupil Position |
-448.80 mm from image plane |
Filter Thread |
M112x0.75 mm |
Size (HxWxL) |
137 x 154 x 377 mm |
Weight |
~ 6.5 kg |
Operating Temp. |
0°C ~ +50°C |
FUJ D60X16.7SR4FE-ZP3C Datasheet (PDF)
