Blue Mango BMH-G365 1/2.3" 2 Megapixel Progressive Scan CMOS Camera with HD-SDI & EX-SDI Outputs with Integrated 36x Optical Zoom (6-216mm), Day/Night, Global Shutter

SKU:
BLU BMH-G365
Availability:
Typically 10-14 days
$1,229.00
Current Stock:


Blue Mango BMH-G365  1/2.3" 2 Megapixel Output Progressive Scan CMOS (Sony IMX392) Camera with HD-SDI & EX-SDI Outputs with Integrated 36x Optical Zoom (6-216mm), Low-Light Sensitivity, Day/Night, Global Shutter, Defog Function, 12 VDC

Features:

• 1/2.3" 2MP Sony Global Shutter CMOS Image Sensor
• HD-SDI, EX-SDI Video Output (Up to 1080p)
• Camera setup by OSD Menu
• Built-in 36x lens supporting Day & Night (6.0mm ~ 216.0mm)
• Supports External trigger input and Strobe output
• Digital Slow Shutter
• Digital Noise Remove (2D+3D)
• Digital Image Stabilizer
• Defog Function



CAMERA

Image Sensor

1/2.3" Sony Global Shutter CMOS Sensor

Total Pixels

1936(H) x 1226(V) = 2.37M pixels

Active Pixels

1936(H) x 1216(V) = 2.35M pixels

Video Format

1080p@60/50fps, 1080p@30/25fps, 720p@60/50fps, 720p@30/25fps

Min. Illumination

Color

0.3 lux / DSS 0.06 lux

BW

0.01lux / DSS 0.002 lux

S/N Ratio

more than 50dB (AGC off)

Video Output

HD-SDI, EX-SDI, TVI, CVBS

LENS

Lens Type

36x Day & Night Zoom Lens

Zoom Ratio

Optical 36x, Digital 32x Zoom

Focal Length

f = 6.0 mm ~ 216.0 mm

Aperture Ratio

F1.5 (wide) ~ F4.8 (tele)

Angle Of View (D, H, V)

WIDE

59.13°

52.62°

31.08°

TELE

2.24°

1.95°

1.10°

CAMERA FUNCTIONS

Camera Title

ID / Title / Zoom Ratio / System Message

Day & Night

Auto / Day / Night / Ext-in

BLC

Off / BLC / HLC

ACE

0 ~ 20 steps

DNR

Auto / Off / Low / Middle / High

Defog

Off / Manual / Auto

HLC

Off / On

Motion Detection

Off / On (3 positions)

Privacy Mask

Off / On (8 positions)

Digital Slow Shutter

Off / 2x / 4x / 8x / 16x / 32x (/64x : 60 or 50fps mode only)

Gain Control

0 ~ 10 steps

White Balance

Auto / One Push / Manual / Indoor / Outdoor

Shutter Speed

1/1 ~ 1/20,000 sec

E.Zoom

Off / MAX 2x ~ 32x

Digital Flip

Off / H / V / H&V





 Downloads



Blue Mango BMH-G365 Datasheet
