Azure Photonics IR1738MAC 1/2" 17mm F3.75 Fixed Iris M12 (S-Mount) Lens, IR Type (800-900nm), 3 Megapixel Rated, Macro Type for Close Working Distances of 100-500mm)

Model #
Copy of AZURE-IR3546CM5M
Availability
Typically 14 days
Shipping
Calculated at checkout
$75.00
Quantity


Technical Information

Specifications:

Model Azure-IR1738MAC
Image Format 1/2'
Resolution 3MP
Focal Length 16.9mm
Back Focus 6.25mm
F/no. 3.75
Iris Type Fixed
Distortion <-0.27%
Lens Effective Diameter

Front (10.71mm)

Back (7.00mm)

Relative Illuminate 86.6%
TTL 23.14mm
Design Wavelength 800-900nm
F.O.V (DxHxV)

1/2 (26.54, 21.35, 16.09)

1/3 (19.61, 16.09, 11.83)

1/4 (13.14, 110.53, 7.90)

Mount M12 X 0.5
Suitable Distance 0.1 - ∞m
Optimum Working Distance 0.56m
Coating 800nm-900nm
Dimension φ15.8×17.9mm
Operating Temperature -20℃~+65℃
Lens Construction 5-4
CRA 11.49



Download Datasheet:
