AZURE Photonics AZURE-3518M3M 2/3" 35mm F1.8 Manual Iris C-Mount Lens, 3 Megapixel Rated

SKU:
AZURE-3518M3M
Availability:
Typically 7-10 days
$139.00
Current Stock:

AZURE Photonics AZURE-3518M3M 2/3" 35mm F1.8 Manual Iris C-Mount Lens, 3 Megapixel Rated

Format: 2/3"

Focal Length: 35mm

Aperture: F1.8

Iris Type: Manual

Mount: C-Mount

SPECIFICATIONS

 Resolution:  120lp/mm(3MP)
 Format :   2/3"
 Mount :  C
 Focal Length:  35mm
 F/No range:  F1.8~F16
 Back Focus:  11.72mm
 Iris Type:  Manual Iris
 Angle of View(D×V×H):

 2/3"

 17.5°× 9.6°×12.8°
 1/2"  11.68°× 7°×9.3°
 1/3"  8.8°× 5.24°×7°
 1/4"  6.56°× 3.94°×5.24°
 Distortion:  <-0.1%
 Focusing Range:  0.25m
 Design Wavelength:    400nm~950nm
 Filter Thread :   M27x0.5
 Dimension :  ¢29x38.2
 Weight :  71g

Dimensions:




Downloads:


AZURE-3518M3M Specification Sheet (PDF)





← Back to AZURE Photonics Lens Page

Lens Type:
35mm
Format:
2/3"
Megapixel Rating:
3 MP
Iris Type:
Manual
Mount Type:
C Mount
