Senko MFA1614-3M 2/3" 16mm F1.4 Manual Iris C-Mount Lens, M27 x 0.5 Filter Thread, 3 Megapixel Rated

SEN MFA1614-3M
Typically in stock
Current Stock:

Format:  2/3"

Focal Length: 16mm

Aperture: F1.4

Iris Type: Manual

Mount: C-Mount


Additional Information

3 Megapixel Rated for Machine Vision.  M27 x 0.5 Filter Thread.  200 lp/mm resolution (center).

Note: This lens model has been successfully tested with the Sony IMX174 1/1.2" format sensor without any vignetting.  (Download datasheet)


Type Manual Mono Mount C
Focal Length 16mm Back Focus 14.59mm
Fno. F 1.4 Mechanical Bf 13.526mm
Design Image Format 2/3" (6.6x8.8mm) Exit Pupil
Operation Range Iris F 1.4 - 16 Filter Size M27 0=0.5
Focus 0.25m ~  Aperture Front
Zoom N/A Rear
Control Iris Manual
Focus Manual Distortion
Zoom N/A Relative Illum
Object Size at MOD VXH   Dimention Ø29.5x37.2mm
MOD   Weight 64 g
Resolution Center 200 lp/mm Operating Temperature  -20°c~+55°c
0.4d 120 lp/mm

Field of View

V  2/3" 23.43°   1/2"    1/3"
H 30.99°



Senko MFA1614-3M Datasheet
